Trail
Rider
Unisex
Wheel Size
29″
Frame Material
Aluminum
Frame Material Details
FORM alloy; molded chainstay, seatstay, and down tube protection
Rear Travel
140mm
Rear Shock
FOX FLOAT DPX2 Performance, size-specific tune, 190mm x 45mm (XS/SM) or 210mm x 52.5mm (MD/LG/XL)
Fork
FOX FLOAT 36 Performance, GRIP damper, EVOL
Offset: 37mm (27.5″), 44mm (29″)
Fork Travel
150mm
Head Tube Diameter
Tapered, 1.125″ top, 1.5″ bottom
Headset
FSA Orbit No.57E, sealed bearings
Handlebar
Rocky Mountain AM, 780mm width, 25mm rise, 9° backsweep, 5° upsweep, 35mm clamp diameter
Stem
Rocky Mountain AM, 40mm length, 5° rise, 35mm bar clamp
Grips
ODI Elite Pro, lock-on
Brakes
Shimano Deore Trail M6120, 4-piston, metal pads
Brake Levers
Shimano Deore Trail M6120
Drivetrain
1x
Shifters
Shimano SLX M7100, 12-speed
Front Derailleur
None
Rear Derailleur
Shimano Deore XT M8100, 12-speed
ISCG Tabs
2-bolt ISCG05
Chainguide
Upper slider
Cranks
Race Face Ride Cinch, 24mm spindle
Length: 165mm (XS), 170mm (SM-XL)
Chainrings
Race Face Ride Cinch, 32 tooth
Bottom Bracket
FSA BB92, 92mm press-fit
Pedals
None
Chain
Shimano Deore M6100, 12-speed
Cassette
Shimano Deore M6100, 12-speed, 10-51 tooth
Rims
WTB ST Light i30 TCS 2.0, 32 hole, tubeless ready (tape and valves included)
Hubs
Front: Rocky Mountain, sealed bearings, 110x15mm Boost
Rear: Shimano SLX, 148x12mm Boost, MICRO SPLINE driver
Spokes
DT Swiss Competition 2.0/1.8/2.0
Tires
Front: Maxxis Minion DHF, 3C MaxxTerra, EXO+, TR, 2.5″ WT
Rear: Maxxis Minion DHR II, 3C MaxxTerra, EXO+, TR, 2.4″ WT
Saddle
WTB Volt Race, 142mm width
Seatpost
Rocky Mountain Toonie dropper
